Surface treatment:
anodizing, polishing, turning, power coating, mill finish etc
Design:
OEM, ODM, or design by ourselves
Equipment:
CNC ,extruding machine, cold drawn machine, heating oven,
straightening machine, cutting machine
Our advantage
Since 2004, we have rich experience in this industry in China;
Good reputation in household foil areas;
We start our productions from aluminum ingot,so we can control the
quality as well;
We have our own development department for new material research;
Sample order is acceptable
All parts of ladder is self manufacturing, we have price advantage.
High performance cost ratio;
Good experience and cooperation with big client in the world;
With Certificate ISO9001-2008;
Fast delivery time;
Good communication skills, and good service and understandings for
customers
All type can be customized made.
Feature
The luster is luminous
High efficient heat transfer, good temperature control
Non-toxic, odorless, impermeable
Compact structure light and economical
Environment friendly, recoverable and recyclable
High reliability and exchanging heat low noise
| Our chemical composition: | | | | | | | | |
| | | | | | | | | |
| Alloy | Si | Fe | Cu | Mn | Mg | Zn | Cr | Ti | code |
| 8011 | 0.5-0.9 | 0.6-1.0 | 0.1 | 0.2 | 0.05 | 0.1 | 0.05 | 0.08 | 1
|
| Mechanical Properties |
| No | Alloy | Temper | Tensile strength | Yield strength | Elongation |
| 1 | 1050 | O/F/H111/H112 | ≥ 65 | ≥ 20 | ≥ 25 |
| 2 | 1100 | O/F/H111/H112 | ≥ 75 | ≥ 20 | ≥ 25 |
| 3 | 1197 | O/F/H111/H112 | ≥ 80 | ≥ 25 | ≥ 20 |
| 4 | 3102 | O/F/H111/H112 | ≥ 75 | ≥ 20 | ≥ 25 |
| 5 | 3R03 | O/F/H111/H112 | ≥ 80 | ≥ 25 | ≥ 20 |
| Mechanical property |
| Alloy Code | Temper | Tensile Strength
Rm(Mpa) | Yield Strength
(Mpa) | Elongation(%) |
TR-010,TR-020,TR-030,TR-040,
TR-050,TR-110,TR-310,TR-116,
TR-316,TR-111,TR-313,TR-121,
TR-131,TR-141,TR-150,TR-151,
TR-156Etc. | O | 95-135* | ≥35* | ≥15* |
| H14 | 140-185 | ≥125 | ≥1.5 |
| H24 | 140-185 | ≥125 | ≥3 |
| H16 | 185-225 | 160 | ≥1 |
| H18 | ≥185 | —— | ≥0.5 |
| TR-166Etc. Tube material | H24 | 185-235 | ≥150 | ≥8 |
| TR-116,TR-316 Etc.tube material | H14 | 140-185 | ≥125 | ≥3 |
| H24 | 140-185 | ≥125 | ≥8 |
